STRATOS Platform Stairlift
Stable, Refined & Intelligent Access for Curved Staircases
The STRATOS Platform Stairlift is a high-performance solution designed for curved, straight, and complex stair layouts, offering safe and elegant wheelchair access in both indoor and outdoor environments. With its robust mechanics, stable guide rails, and refined architectural design, STRATOS ensures smooth, quiet, and reliable vertical mobility while blending seamlessly into any space.
Its copact construction allows installation on most existing staircases, making it an ideal retrofit solution for residential, commercial, and public buildings where elevators are not feasible.
can be used at
House
Business
Your are here
Technical Specifications
Load Capacity
225 kg (optional upgrade to 300 kg)
Stair Incline
0° – 47°
Travel Speed
0.06 – 0.10 m/s
Noise Level
Below 60 dB
Drive System
Rack and pinion
Power Supply
1 × 230V / 50–60 Hz
Surface Finishes
• Standard: RAL 9007 or RAL 7035 • Optional: Any RAL color • Optional: Stainless steel track and platform surfaces
Optional Configuration
Folding seat for ambulant users
Key Features
- Compact and aesthetic platform design
- Stable rack-and-pinion drive system on lower guide tube
- Clean upper guide rail serving as a comfortable handrail
- Smooth, quiet, and secure platform movement
- Suitable for straight, curved, and complex staircases
- Indoor and outdoor installation
- Fast and cost-effective retrofitting
- Diagnostic display for system status and maintenance monitoring
- Easy and quick assembly
- Available in any RAL color
- Luxury version with stainless steel track and platform covers
