Doors & Parking Access Solutions
Garage Door Automation
Automatic Operators for Residential and Industrial Doors
FAAC Garage Door Automation systems provide reliable and efficient motorised solutions for automating sectional garage doors and up-and-over doors, tailored for residential, condominium, and light industrial applications. These systems are designed to meet safety, energy-saving, and user-comfort requirements while adapting to various door types and use cases.
Overview of Garage Door Automation Systems
FAAC offers automation systems suitable for:
- Sectional garage doors – horizontal panel doors that slide vertically along tracks.
- Up-and-over doors – traditional single-leaf doors that tilt up and out.
Both categories are engineered for smooth, safe operation and easy integration with access control devices.
can be used at
House
Business
Vehicles
Pools
Your are here
Featured Garage Door Operators
D600 Electromechanical Operator
A 24V electromechanical operator with belt or chain drive, ideal for sectional doors and balanced door types. It features quick installation with pre-assembled rail and rotation coupling, along with electronic deceleration and obstacle detection.
Key Specifications
- Power supply: 220–240V AC, 50/60 Hz
- Motor power: 220 W
- Maximum thrust: 600 N
- Max. carriage speed: 6.6 m/min
- Noise level: 45 dB(A)
- Operating temperature: –20 °C to +55 °C
- Protection class: IP20 (indoor use)
- Weight: 6.2 kg
- Includes electronic control unit and courtesy light timer.
D700 HS Garage Door Operator
A higher-performance operator in the D600 family, featuring electromechanical drive for sectional doors with fast, reliable operation and enhanced features for frequent usage.
Highlights
- Electromechanical design with built-in control unit
- Timed courtesy light for convenience
- Internal release device for manual operation when needed
- Compatible with safety accessories and remote controls.
D1000 Garage Door Operator
Designed for larger or heavier sectional and spring/counterbalanced up-and-over doors, the D1000 operator features enhanced thrust force and easy installation.
Key Specifications
- Maximum thrust force: 1000 N
- Motor power: 350 W
- Carriage speed: 6.6 m/min
- Noise: 45 dB(A)
- Chain/belt transmission with adjustable travel limit and electronic slow-down
- Quiet belt drive as standard
- Non-reversing facility eliminates need for separate locks or bolts.
580 Hydraulic Garage Door Operator
A 230V hydraulic operator designed for up-and-over doors, offering powerful and quiet operation with hydraulic locking for added safety and performance.
Key Specifications
- Power supply: 220–240V AC
- Max. door dimensions: 3.5 × 3.0 m (single unit) / up to 6 × 4 m with two operators
- Max. door weight: 15 kg/m²
- Use frequency: 60 cycles/hour
- Hydraulic anti-crushing safety device and wind resistance hold
- Protection class: IP55
- Weight: 12 kg.
Key Benefits
- Flexible compatibility — Works with both sectional and up-and-over garage doors.
- Safety built-in — Designed with safety features to comply with modern standards while ensuring reliable operation.
- Energy efficiency — Mechanisms designed for low-power consumption with optional backup battery support for uninterrupted use.
- Easy installation — Pre-assembled rails and straightforward mechanical coupling minimises installation time.
Ideal Applications
FAAC garage door automation systems are suitable for:
- Residential garage doors
- Multi-tenant condominium buildings
- Light industrial and commercial garage access
- Integrated smart access control installations.
